01PRECAST INTERLOCKING BLOCK SYSTEM

Building blocks
that lock,
not stack.

No mortar. No plaster. A precision-engineered interlocking block from Urban Puzzle Investment, designed and produced in the Sultanate of Oman.

Request a Quote View Specs
3×Faster installation
0Mortar required
2040Oman Vision aligned
Urban Puzzle interlocking block H 9 cm W 15 cm L 30 cm
URBAN PUZZLE INVESTMENT◆MUSCAT, OMAN◆PRECAST INTERLOCKING SYSTEMS◆OMAN VISION 2040◆URBAN PUZZLE INVESTMENT◆MUSCAT, OMAN◆PRECAST INTERLOCKING SYSTEMS◆OMAN VISION 2040◆

02ANATOMY OF A BLOCK

Six faces. One system.

Scroll through every angle of the block as captured from our production CAD model.

Top perspective Top wireframe Front wireframe Right wireframe Back wireframe Left wireframe Bottom wireframe Bottom perspective
01 Perspective — Top
View 01 / 08

The double-bore face

The top face carries two cylindrical bores — the structural and service core of the entire system, designed to stack and align block to block without mortar.

View 02 / 08

Plan tolerance

300 × 150 mm footprint with two bores centred on the long axis, spaced for predictable, repeatable coursing across a wall run.

View 03 / 08

Elevation profile

A 90 mm rise lines up cleanly with standard openings, lintels, and slab edges — no cutting required on most runs.

View 04 / 08

Bore depth — right

Bores run nearly full height, leaving a thin structural floor — rigid enough for the unit, clear for conduit and rebar.

View 05 / 08

Mirror check — rear

Every block is symmetric front to back — no orientation guesswork for the crew on site.

View 06 / 08

Bore depth — left

Left and right read identically — a deliberate tolerance keeping every unit interchangeable across a pallet or project.

View 07 / 08

The underside

The base mirrors the top bore pattern so interlocking geometry continues seamlessly as the wall rises.

View 08 / 08

Full unit — base up

Flipped: a clean shoulder, a true bore, a connection that needs no wet trades.

03DATASHEET

Engineered to a millimetre.

PLAN VIEW (TOP) WIDTH — 150 mm LENGTH — 300 mm OUTER BORE Ø 80 mm INNER BORE Ø 70 mm FRONT ELEVATION HEIGHT — 90 mm
Overall height90 mm(9 cm)
Overall width150 mm(15 cm)
Overall length300 mm(30 cm)
Outer bore diameterØ 80 mm(8 cm)
Inner bore diameterØ 70 mm(7 cm)
Bore engineeringOuter bore sized for structural connections between courses; inner bore raises compressive strength while leaving clear passage for electrical and plumbing runs.

04BEYOND THE BLOCK

A full materials system.

The interlocking block is the flagship — but it ships alongside coatings, adhesives, and machinery from the same R&D team.

01

Puzzle Interlocking Blocks

  • No mortar or plaster required
  • 3× faster installation
  • High insulation — heat, sound, moisture
  • Strong, lightweight, customizable
  • Eco-friendly & recyclable
02

Block Production Machinery

  • Proprietary, patent-pending technology
  • High-speed, low-cost production
  • Modular design for export
  • International compliance
03

Fiber-Reinforced Waterproofing

  • Water-based, eco-friendly, odourless
  • Crack-resistant and flexible
  • Excellent adhesion on all substrates
04

Insulating Façade Paint

  • Anti-UV, stain-resistant, water-repellent
  • Long-lasting, non-toxic finish
05

Anti-Rust Coating

  • Water-based, prevents corrosion
  • Multiple colour options
06

Tile & Concrete Adhesives

  • Strong bonding — EU & US certified
  • Low-energy manufacturing process
Coming Soon — Next-Gen Innovation
Underwater concrete, patented formulation Decorative bricks & anti-efflorescent stones Lightweight prefab panels & foam houses Cement-free blocks & ready-mix concrete Precast stairs from stone waste

05THE CASE FOR US

Why Urban Puzzle?

01

Ownership

We design, build, and control our own proprietary machinery — complete flexibility to localize for any market.

02

Efficiency

Faster to build, higher performing, more cost-effective than traditional systems.

03

Sustainability

Water-based coatings to mortar-free blocks — reducing environmental impact across the lifecycle.

04

Scalability

Export-ready manufacturing and a professional sales network positioned for the GCC and beyond.

05

Expertise

Decades of industrial, financial, and marketing expertise backed by international R&D partners.

06FOUNDERS & LEADERSHIP

Built by people who've built before.

Chairman

Dr. Seyed Mostafa Shahrestani

Financial economist with 24 years in global investment, startup development, and corporate structuring across Europe, the Middle East, and Asia.

CEO

Eng. Mohammad Javad Hossein

Senior industrial expert with 35+ years in manufacturing, project management, and metallurgy focused on sustainable production technologies.

Commercial Manager

Bsc. Ali Baqeri

Sales and marketing strategist with proven success launching innovative products and growing market presence across the GCC.

Technical Manager

Dr. Mohsen Falahatkar Gashti

Ph.D. in structural engineering focused on construction materials, geopolymer concrete, and reinforced-concrete structures.

07GET A QUOTE

Tell us about your project.

Share a few details and our commercial team will follow up with pricing, lead times, and delivery options across Oman and the GCC.

Muscat, Sultanate of Oman

Thank you — your inquiry has been received. Our team will contact you shortly.
